Key Features
- Proven Technology: Simple and robust connection ensures dependable system reliability.
- Fast, Flameless Installation: AP Stainless technology reduces installation and repair time by over 50%, eliminating the need for welding or threading.
- Vibration Absorption: Elastomeric connections accommodate vibration, expansion, and contraction.
- Corrosion Resistance: Chromium dioxide layer provides superior protection in corrosive environments.
- Fluid Integrity: No risk of contamination to conveyed fluids.
- UV Resistant: No degradation from UV exposure.
- Thermal Stability: Low expansion factor of 16 ensures dimensional consistency under temperature fluctuations.
Size & Connection Options
- Available Sizes: 1 ½” to 10″
- Sizes 5″-10″ includes (2) Union Connectors
Connection Types:
- NPT Male Threaded Joints are needed for 1 1/2″ and 2″
- ANSI Flanges are needed for 2 1/2″ to 10″
Material & Seals
- Material: 304 Stainless Steel
- Standard Seals: EPDM for general applications
- Optional Seals: FKM for high temperature and chemical resistance
Applications
- Compressed Air & Inert Gases: Especially in corrosive environments and food service operations
- Chemical Processing: Excellent corrosion resistance
- Cooling Systems: Coolers, cooling towers, and chillers (glycol)
- Process Water Systems
- Industrial Oils: Including cutting fluids
- Power Generation Facilities
Certifications
- ASME B31.1, B31.3, B31.9
- ASTM A312
- ISO 9001, 14001, 45001
Warranty
All AP Stainless fittings are backed by a 10-year warranty, ensuring peace of mind and long-term value.
