Union Seal FKM
The Union Seal with FKM (Viton®) is specifically designed for high-temperature applications in AIRpipe aluminum compressed air systems. Made from premium fluoroelastomer material, this seal delivers exceptional resistance to heat, chemicals, and oils, ensuring reliable performance in demanding industrial environments.
Key Features:
- Seal Material: FKM / Viton
- Temperature Range: Up to +200°C (392°F) for continuous operation
- Chemical Resistance: Excellent compatibility with oils, fuels, and aggressive chemicals
- Durability: Superior aging, ozone, and compression set resistance
- Application: Ideal for AIRpipe aluminum systems operating under high thermal and chemical stress
- Available Sizes: 3/4″ up to 10″
Benefits:
- Maintains airtight integrity in extreme conditions
- Reduces maintenance and downtime
- Ensures long-lasting performance in high-temperature environments
Additional information
Weight
0.033 lbs
AIRpipe Outer Dimension
20mm (3/4"), 25mm (1"), 40mm (1-1/2"), 50mm (2"), 63mm (2-1/2"), 80mm (3"), 100mm (4"), 150mm (6"), 200mm (8"), 250mm (10")
Color
Brown Orange
Features
High Flow
Pressure
188 PSI, 232 PSI, 29.9 inHg (99% vacuum), 300 PSI
Connection
Grab Ring Clamping Style, Lugged Ring Clamping Style
Temperature
Material
FKM
AIRpipe Certification
ASME, ASTM, CE, CRN, EN, ISO 14001, ISO 8573-1, ISO 9001, TS, TUV, UL
