Key Features
- Proven Technology: Simple and robust threaded connection ensures long-term system reliability.
- Flameless Installation: No welding or soldering—reduces installation and repair time by over 50%.
- Versatile Conveyance: Seal and material options allow for the conveyance of nearly any liquid or gas.
- Dynamic System Response: Elastomeric connections absorb vibration, expansion, and contraction.
- Corrosion Resistance: Chromium dioxide layer protects against rust and environmental degradation.
- Fluid Safety: No risk of contamination to conveyed fluids.
- UV Stability: No impact from UV exposure, ideal for outdoor installations.
Size Range
- Available Sizes: 1/2″ to 1 1/4″
- Connection Type: Female NPT threads on all three ends
- Built-in Sealing: Designed for gases and liquids
- Extended Fitting Sleeve: Maintains pipe alignment and flow efficiency
Material & Seals
- Material: 304 Stainless Steel
- Seals:
- EPDM (standard for press connections)
- FKM (for high temperature and chemical resistance)
Applications
- Chilled/Cooled Water
- Hot Water
- Process Water
- Low Pressure Steam
- Compressed Air & Inert Gases
- Vacuum Systems
- Chemicals & Hydraulic Oils
- Acid & Caustic Solutions
- Wastewater
- Diesel Exhaust Fluid (DEF)
Certifications
- ASME B31.1, B31.3, B31.9
- ASTM A312
- ISO 9001, 14001, 45001
Warranty
- 10-Year Warranty on all AP Stainless fittings
