Key Advantages
- Reliable Technology: Proven design with a simple, robust connection for dependable system performance.
- Efficient Installation: AP Stainless is a flameless, clean system that reduces installation and repair time—cutting traditional costs by over 50%.
- Vibration Absorption: Elastomeric connections accommodate vibration, expansion, and contraction for enhanced system integrity.
- Corrosion Protection: Chromium dioxide layer provides excellent resistance to corrosion.
- Fluid Safety: No risk of contamination to conveyed fluids.
- UV Resistant: No degradation from UV exposure.
- Thermal Stability: Low expansion factor of 16 ensures dimensional consistency under thermal stress.
Specifications
- Sizes Available: ½” to 2″
- Includes: (2) Union Connectors
Material & Seals
- Material: 304 Stainless Steel
- Seals:
- EPDM (standard for press connections)
- FKM (for high temperature and chemical resistance)
Applications
- Compressed Air & Inert Gases: Especially in corrosive environments and food service operations
- Chemical Processing: Excellent corrosion resistance
- Cooling Systems: Coolers, cooling towers, and chillers (glycol)
- Process Water Systems
- Industrial Oils: Including cutting fluids
- Power Generation Facilities
Certifications
- ASME B31.1 – Power Piping
- ASME B31.3 – Process Piping
- ASME B31.9 – Building Services Piping
- ASTM A312 – Seamless and Welded Austenitic Stainless Steel Pipes
- ISO 8573-1 – Compressed Air Quality Standards
Warranty
Backed by a 10-year warranty on all AP Stainless fittings for peace of mind and long-term value.
